Gallery
Auto Data Access
<%@ Page Language="C#" Description="dotnetCHARTING Component" %>
<%@ Register TagPrefix="dotnet" Namespace="dotnetCHARTING" Assembly="dotnetCHARTING"%>
<%@ Import Namespace="System.Drawing" %>
<%@ Import Namespace="System.Drawing.Drawing2D" %>
<script runat="server">
void Page_Load(Object sender,EventArgs e)
{
Chart.TempDirectory = "temp";
Chart.Debug = true;
Chart.DefaultSeries.Type = SeriesType.Line;
Chart.Size = "600x350";
//Chart.Title = ".netCHARTING Sample";
Chart.LegendBox.Visible = false;
Chart.XAxis.Scale = Scale.Time;
Chart.XAxis.FormatString="MM/dd/yy";
// Demonstrates accessing elements within a database populated without the use of the dataEngine.
Series s = new Series();
s.ConnectionString = ConfigurationManager.AppSettings["DNCConnectionString"];
s.StartDate=new System.DateTime(2022,1,1,0,0,0);
s.EndDate = new System.DateTime(2022,1,31,23,59,59);
s.SqlStatement= "SELECT OrderDate, Total FROM Orders WHERE OrderDate >= #STARTDATE# AND OrderDate <= #ENDDATE# ORDER BY Orders.OrderDate";
for(int i = 0; i < 70; i++)
{
s.Elements[i].Color = Color.FromArgb(210,((i*2)%255),((i+50)%255));
}
Chart.SeriesCollection.Add(s);
}
</script>
<html xmlns="http://www.w3.org/1999/xhtml">
<head>
<title>.netCHARTING Sample</title> </head>
<body>
<div align="center">
<dotnet:Chart id="Chart" runat="server"/>
</div>
</body>
</html>
<%@ Page Language="vb" Description="dotnetCHARTING Component" %>
<%@ Register TagPrefix="dotnet" Namespace="dotnetCHARTING" Assembly="dotnetCHARTING"%>
<%@ Import Namespace="System.Drawing" %>
<%@ Import Namespace="System.Drawing.Drawing2D" %>
<script runat="server">
Sub Page_Load(ByVal sender As Object, ByVal e As EventArgs)
Chart.TempDirectory = "temp"
Chart.Debug = True
Chart.DefaultSeries.Type = SeriesType.Line
Chart.Size = "600x350"
'Chart.Title = ".netCHARTING Sample";
Chart.LegendBox.Visible = False
Chart.XAxis.Scale = Scale.Time
Chart.XAxis.FormatString="MM/dd/yy"
' Demonstrates accessing elements within a database populated without the use of the dataEngine.
Dim s As Series = New Series()
s.ConnectionString = ConfigurationManager.AppSettings("DNCConnectionString")
s.StartDate = New System.DateTime(2022,1,1,0,0,0)
s.EndDate = New System.DateTime(2022,1,31,23,59,59)
s.SqlStatement= "SELECT OrderDate, Total FROM Orders WHERE OrderDate >= #STARTDATE# AND OrderDate <= #ENDDATE# ORDER BY Orders.OrderDate"
For i As Integer = 0 To 69
s.Elements(i).Color = Color.FromArgb(210,((i*2) Mod 255),((i+50) Mod 255))
Next i
Chart.SeriesCollection.Add(s)
End Sub
</script>
<html xmlns="http://www.w3.org/1999/xhtml">
<head>
<title>.netCHARTING Sample</title> </head>
<body>
<div align="center">
<dotnet:Chart id="Chart" runat="server"/>
</div>
</body>
</html>
- Sample FilenameAutoDataAccess.aspx
- Version4.1
- Uses DatabaseYes
