Bubble
Demonstrates 2 series using the bubble type.
<%@ Page Language="C#" Description="dotnetCHARTING Component"%>
<%@ Register TagPrefix="dotnet" Namespace="dotnetCHARTING" Assembly="dotnetCHARTING"%>
<%@ Import Namespace="System.Drawing" %>
<script runat="server">
void Page_Load(Object sender,EventArgs e)
{
//set global properties
Chart.Title="Bubble sample";
Chart.TempDirectory="temp";
Chart.Debug=true;
Chart.Type = ChartType.Bubble;
Chart.Use3D=true;
Chart.DefaultAxis.NumberPercision=1;
Chart.DefaultSeries.DefaultElement.ShowValue=true;
Chart.DefaultSeries.DefaultElement.LabelTemplate="(%Xvalue,%Yvalue)";
Chart.DefaultSeries.DefaultElement.ForceMarker=false;
Chart.Palette = new Color [] {Color.Blue,Color.Red,Color.Yellow};
//Add a series
Chart.Series.Name="series 1";
Chart.Series.Element = new Element("",0.4,7.5,1);
Chart.Series.Elements.Add();
Chart.Series.Element = new Element("",2.5,4,1.5);
Chart.Series.Elements.Add();
Chart.SeriesCollection.Add();
//Add a series
Chart.Series.Name="series 2";
Chart.Series.Element = new Element("",1.2,11,1);
Chart.Series.Elements.Add();
Chart.Series.Element = new Element("",2.5,-6,0.6);
Chart.Series.Elements.Add();
Chart.SeriesCollection.Add();
//Add a series
Chart.Series.Name="series 3";
Chart.Series.Element = new Element("",1,-6,1);
Chart.Series.Elements.Add();
Chart.Series.Element = new Element("",3,14,1.3);
Chart.Series.Elements.Add();
Chart.SeriesCollection.Add();
}
</script>
<html xmlns="http://www.w3.org/1999/xhtml"><head><title>Bubble sample</title></head>
<body>
<div style="text-align:center">
<dotnet:Chart id="Chart" runat="server"/>
</div>
</body>
</html>
<%@ Page Language="vb" Description="dotnetCHARTING Component"%>
<%@ Register TagPrefix="dotnet" Namespace="dotnetCHARTING" Assembly="dotnetCHARTING"%>
<%@ Import Namespace="System.Drawing" %>
<script runat="server">
Sub Page_Load(ByVal sender As Object, ByVal e As EventArgs)
'set global properties
Chart.Title="Bubble sample"
Chart.TempDirectory="temp"
Chart.Debug=True
Chart.Type = ChartType.Bubble
Chart.Use3D=True
Chart.DefaultAxis.NumberPercision=1
Chart.DefaultSeries.DefaultElement.ShowValue=True
Chart.DefaultSeries.DefaultElement.LabelTemplate="(%Xvalue,%Yvalue)"
Chart.DefaultSeries.DefaultElement.ForceMarker=False
Chart.Palette = New Color () {Color.Blue,Color.Red,Color.Yellow}
'Add a series
Chart.Series.Name="series 1"
Chart.Series.Element = New Element("",0.4,7.5,1)
Chart.Series.Elements.Add()
Chart.Series.Element = New Element("",2.5,4,1.5)
Chart.Series.Elements.Add()
Chart.SeriesCollection.Add()
'Add a series
Chart.Series.Name="series 2"
Chart.Series.Element = New Element("",1.2,11,1)
Chart.Series.Elements.Add()
Chart.Series.Element = New Element("",2.5,-6,0.6)
Chart.Series.Elements.Add()
Chart.SeriesCollection.Add()
'Add a series
Chart.Series.Name="series 3"
Chart.Series.Element = New Element("",1,-6,1)
Chart.Series.Elements.Add()
Chart.Series.Element = New Element("",3,14,1.3)
Chart.Series.Elements.Add()
Chart.SeriesCollection.Add()
End Sub
</script>
<html xmlns="http://www.w3.org/1999/xhtml"><head><title>Bubble sample</title></head>
<body>
<div style="text-align:center">
<dotnet:Chart id="Chart" runat="server"/>
</div>
</body>
</html>
